硬禾仪器用数据传输及控制协议

本逻辑用于将高速ADC采集到的数据进行缓存，并根据上位机的需要，从缓存的数据中选出用于显示的部分进行传输，传输的方式可以是：

  • 串口UART
  • BLE
  • WiFi
  • SPI

FPGA的作用负责解析控制器发来的控制字，并根据控制字的内容从缓存中选取需要的数据

  1. 由ADC获取的数据或送往DAC的数据：LVDS：250MHz/8bits/4Lanes， 并行：100MHz/14bits
  2. 需要显示的数据：20帧/秒 * 1KPoints/帧 * 10bit/points = 200kbps
  3. 存储深度：ADC - 8K * 10bits * 2（通道）= 20KBytes， DAC - 4K * 12bits * 2 = 12KByte，总计32KBytes

未来在FPGA里面可以扩展的数据处理功能：

  1. FFT
  2. 数字滤波
  3. 模式识别
  4. 机器学习

FPGA内部的框图如下： instru_control_data_protocol.png

数据采集FPGA逻辑功能

参考文档：

示波器部分的功能

主要分为两部分：

双口RAM

根据FPGA的内部Block RAM或外扩的RAM的实际情况设定双口RAM的大小，一般我们使用的Lattice XO2系列的FPGA内带的Block RAM为96kbits，如果采用双通道8位的高速ADC,则每个通道可以使用的RAM空间为48Kbits ~ 6KByte，考虑到高速ADC可以采用更高分辨率，比如12bit，96Kbits ~ 12bits * 2 * 4K，每个通道为4KB的存储深度。

并/串变换及控制逻辑

任意波形发生器部分

直流稳压电源部分

Waveformlive的仪器控制协议参考

  • 下面的JSON数据已扩展以提高可读性。在传输之前，应将所有JSON缩小（删除空白）.
  • 除非另有说明，否则使用HTTP时，所有命令均使用POST方法发送.
  • 所有Digilent Instrumentation协议命令必须是JSON对象或分块传输:
    • JSON对象
      • 必须以'{'字符开头，并以'}'字符结尾.
      • 可能后跟一个或多个'\ r \ n'.
    • 大块转移
      • 由一个或多个块组成.
      • 每个块必须以ASCII十六进制格式的块中的字节数开头，后跟一个'\ r \ n'，二进制数据和一个'\ r \ n'.
        • 块长度在块长度和数据之间不包含'\ r \ n'.
        • 块长度不包含二进制数据后的尾随'\ r \ n'.
      • 每个分块传输都以零长度的分块终止.
      • Ex.
6\r\n
chunk1\r\n
8\r\n
somedata\r\n
E\r\n
 in\r\n\r\nchunks.\r\n
0\r\n
\r\n

多命令

可以使用多命令在单个事务中发送多个命令。

举例:

Command

{
   "dc":{
      "1":[
         {
            "command":"setVoltage",
            "voltage":3300
         },
         {
            "command":"getVoltage"
         }
      ],
      "2":[
         {
            "command":"setVoltage",
            "voltage":5000
         }
      ]
   }
}

Response

{
   "dc":{
      "1":[
         {
            "command":"setVoltage",
            "statusCode":0,
            "wait":500
         },
         {
            "command":"getVoltage",
            "statusCode":0,
            "wait":100,
            "voltage":3300
         }
      ],
      "2":[
         {
            "command":"setVoltage",
            "statusCode":0,
            "wait":500
         }
      ]
   }
}



波形发生器部分

提供访问任意波形发生器的数据和功能的命令

获得当前状态

获得仪器通道的当前状态、

命令
  • awg - (Object) - 任意波形发生器的目标.
    • # - (Array<Object>) - An array of command objects to apply to the awg channel.
      • command - (String) - 获取当前状态的命令: “getCurrentState”
响应
  • awg - (Object) - 任意波形发生器的目标
    • # - (Array<Object>) - An array of command objects applied to the awg channel.
      • command - (String) - The Get Current State command: “getCurrentState”
      • statusCode - (Integer) - A numeric value representing the device status.
          * ** wait ** - (Integer) - The number of ms to wait before the device is ready to process another command.
  * ** state ** - (String) - The instrument channel state: "idle" or "running".
  * ** waveType ** - (String) - The waveform type: "sine", "square", "triangle", "dc", "sawtooth", "arbitrary", or "none".
  * ** actualSignalFreq ** - (Integer) -  The actual waveform frequency in mHz.
  * ** actualVpp ** - (Integer) - The actual peak-to-peak voltage in mV.
  * ** actualVOffset ** - (Integer) - The actual voltage offset in mV.
例子

命令

{
    "awg": {
        "1": [
            {
                "command": "getCurrentState"
            }
        ]
    }
}

响应

{
    "awg": {
        "1": [
            {
                "command": "getCurrentState",
                "statusCode": 0,
                "wait": 0,
                "state": "running",
                "waveType": "sine",
                "actualSignalFreq": 1000000,
                "actualVpp": 3000,
                "actualVOffset": 0
            }
        ]
    }
}


设置通用波形

设置AWG的通道参数以输出正常的波形

命令
  • awg - (Object) - The arbitrary waveform generator object.
    • # - (Array<Object>) - An array of command objects to apply to the awg channel.
      • command - (String) - The Set Regular Waveform command: “setRegularWaveform”
      • signalType - (String) - The waveform type: “sine”, “square”, “triangle”, “dc”, “sawtooth”, “arbitrary”, or “none”.
      • signalFreq - (Integer) - The signal frequency in mHz.
      • vpp - (Integer) - The peak-to-peak voltage in mV.
      • vOffset - (Integer) - The voltage offset in mV.
响应
  • awg - (Object) - The arbitrary waveform generator object.
    • # - (Array<Object>) - An array of command objects applied to the awg channel.
      • command - (String) - The Set Regular Waveform command: “setRegularWaveform”
      • statusCode - (Integer) - A numeric value representing the device status. See reference/software/digilent-instrumentation-protocol/status-codes
      • wait - (Integer) - The number of ms to wait before the device is ready to process another command.
          * **actualSignalFreq** - (Integer) -  The actual waveform frequency in mHz.
  * **actualVpp** - (Integer) - The actual peak-to-peak voltage in mV.
  * **actualVOffset** - (Integer) - The actual voltage offset in mV.
举例(波形)

Command

{
   "awg":{
      "1":[
         {
            "command":"setRegularWaveform",
            "signalType":"sine",
            "signalFreq":1000000,
            "vpp":3000,
            "vOffset":0
         }
      ]
   }
}

Response

{
   "awg":{
      "1":[
         {
            "command":"setRegularWaveform",
            "statusCode":0,
            "wait":0,
            "actualSignalFreq": 1000000,
            "actualVpp": 3000,
            "actualVOffset":0
         }
      ]
   }
}



运行

运行AWG通道

命令
  • awg - (Object) - The arbitrary waveform generator object.
    • # - (Array<Object>) - An array of command objects to apply to the awg channel.
      • command - (String) - The Run command: “run”
响应
  • awg - (Object) - The arbitrary waveform generator object.
    • # - (Array<Object>) - An array of command objects applied to the awg channel.

举例:

Command

{
   "awg":{
      "1":[
         {
            "command":"run"
         }
      ]
   }
}

Response

{
   "awg":{
      "1":[
         {
            "command":"run",
            "statusCode":0,
            "wait":0
         }
      ]
   }
}



停止

停止AWG通道

命令

  • awg - (Object) - The arbitrary waveform generator object.
    • # - (Array<Object>) - An array of command objects to apply to the awg channel.
      • command - (String) - The Stop command: “stop”

响应

  • awg - (Object) - The arbitrary waveform generator object.
    • # - (Array<Object>) - An array of command objects applied to the awg channel.

举例:

Command

{
   "awg":{
      "1":[
         {
            "command":"stop"
         }
      ]
   }
}

Response

{
   "awg":{
      "1":[
         {
            "command":"stop",
            "statusCode":0,
            "wait":0
         }
      ]
   }
}



直流电压

提供访问直流电压数据和函数的命令

获取当前状态

Get the current state of the instrument's channel

命令

  • dc - (Object) - The DC power supply object.
    • # - (Array<Object>) - An array of command objects to apply to the DC power supply channel.
      • command - (String) - The Get Current State command: “getCurrentState”

响应

  • gpio - (Object) - The DC power supply object.
    • # - (Array<Object>) - An array of command objects applied to the DC power supply channel.
      • command - (String) - The Get Current State command: “getCurrentState”
      • statusCode - (Integer) - A numeric value representing the device status. See reference/software/digilent-instrumentation-protocol/status-codes
      • wait - (Integer) - The number of ms to wait before the device is ready to process another command.
          * **state** - (String) - The current state of the channel: "idle" or "running".
  * **voltage** - (Integer) - The current measured value of the channel in mV.

        #### 举例

命令

{
    "dc": {
        "1": [
            {
                "command":"getCurrentState"
            }
        ]
    }
}

响应

{
    "dc": {
        "1": [
            {
                "command": "getCurrentState",
                "statusCode": 0,
                "wait": 0,
                "state": "idle",
                "voltage": 3300
            }
        ]
    }
}


获取电压值

Get the output voltage(s) of the specified DC power supply channel(s).

命令

  • dc - (Object) - The DC power supply object.
    • # - (Array<Object>) - An array of command objects to apply to the DC power supply channel.
      • command - (String) - The Get Voltage command: “getVoltage”

响应

  • gpio - (Object) - The DC power supply object.
    • # - (Array<Object>) - An array of command objects applied to the DC power supply channel.
      • command - (String) - The Get Voltage command: “getVoltage”
      • statusCode - (Integer) - A numeric value representing the device status. See reference/software/digilent-instrumentation-protocol/status-codes
      • wait - (Integer) - The number of ms to wait before the device is ready to process another command.
          * **voltage**  - (Integer) - The current measured value of the channel in mV.

#### 举例

命令

{
   "dc":{
      "1":[
         {
            "command":"getVoltage"
         }
      ]
   }
}

Response

{
   "dc":{
      "1":[
         {
            "command":"getVoltage",
            "statusCode":0,
            "wait":100,
            "voltage":3300
         }
      ]
   }
}



设置电压

Set the output voltage(s) of the specified DC power supply channel(s).

命令

  • dc - (Object) - The DC power supply object.
    • # - (Array<Object>) - An array of command objects to apply to the DC power supply channel.
      • command - (String) - The Set Current State command: “setCurrentState”
      • voltage - (Integer) - The desired voltage in mV.

响应

  • gpio - (Object) - The DC power supply object.
    • # - (Array<Object>) - An array of command objects applied to the DC power supply channel.
      • command - (String) - The Set Current State command: “setCurrentState”
      • statusCode - (Integer) - A numeric value representing the device status. See reference/software/digilent-instrumentation-protocol/status-codes
      • wait - (Integer) - The number of ms to wait before the device is ready to process another command.
        #### 举例:

Command

{
   "dc":{
      "1":[
         {
            "command":"setVoltage",
            "voltage":3300
         }
      ]
   }
}

Response

{
   "dc":{
      "1":[
         {
            "command":"setVoltage",
            "statusCode":0,
            "wait":500
         }
      ]
   }
}
